The Ubiquiti Gen 2 ETH-SP-G2 is a cost-effective solution for protecting outdoor Ethernet devices from damaging electrostatic discharge and surges. Since all Ubiquiti® airMAX® devices already have robust ESD protection built in, adding the ETH-SP-G2 to the installation provides an additional layer of protection to the network. The ETH-SP-G2 is engineered to protect Power-over-Ethernet (PoE) or non-PoE devices with connection speeds of up to 1 Gbps. Two passive, surge-protected RJ45 connections provide maximum equipment compatibility.

Brand New - A brand-new, unused, unopened, undamaged item in its original packaging.

This item comes with a 12-month Manufacturer's warranty.

• Low-Cost Protection and Fast Installation.
• Protects Outdoor Ethernet Devices.
• Compatible with 10/100/1000 Mbps Networks.
• Suits PoE and non-PoE devices.
• 91 x 61 x 32.5 mm, 0.80 g weight.
• IEEE 802.3af PoE Support.
• 2x RJ45 Female Connectors.

• Product Type: Ethernet Surge Protector
• Interface Connections: (2) RJ45 Female Connectors
• DC Spark-Over Voltage: 90V @ 100V/s
• Maximum Impulse Spark-Over Voltage: 700V @ 1kV/µs
• Discharge Current: 10kA+
• Maximum Insulation Resistance: 1G ohm @ 50V
• Maximum Capacitance: 1.0 pF @ 1 MHz
• Data Line Protection: RJ45 10/100/1000 Ethernet
• IEEE 802.3af PoE Support: Yes
• Shock and Vibration Certification: ETSI300-019-1.4 Standard

• Ubiquiti G2 Ethernet Surge Protector ETH-SP-G2
• User Guide
