Aten 8-Port Multi-Interface Cat 5 KVM Switch KH1508A-AX-U
The KH1508 KVM Switch is a control unit that allows access to multiple computers from a single KVM console. The KH1508 features RJ-45 connectors and Cat 5 cable to link to the computers.
The KH1508 KVM Switch is a control unit that allows access to multiple computers from a single KVM console. The KH1508 features RJ-45 connectors and Cat 5 cable to link to the computers. Combined with Auto-Single Compensation(ASC) signals can travel up to 40 meters and still maintain high video resolution. Utilizing PS/2 and USB KVM Adapter Cables for the final linkup, the KH1508 permits any combination of PCs, Macs, Sun computers, and serial devices to coexist on the installation.
CONDITION
Brand New - A brand-new, unused, unopened, undamaged item in its original packaging.
WARRANTY
This item comes with a 24-month manufacturer's warranty.
FEATURES
• A single console controls up to 8 computers
• Dedicated chain ports - daisy chain up to 31 additional units - control up to 256 computers from a single console
• Extends the distance between computers and switch - up to 40 m (130') for resolutions of 1280 x 1024 @ 60Hz, 30m (100') for resolution of 1600 x 1200 @ 60Hz
• Custom ASIC (patent pending) auto-senses station's position on daisy chained installations - no need for manual DIP switch setting - front panel LED indicates station's position
• Multiplatform support: PC, Mac, Sun and terminal-based systems
• No software required - convenient computer selection via port selection switches, Hotkeys and intuitive On Screen Display (OSD) menus
• Auto Scan feature for monitoring user-selected computers
• Hot Pluggable - add or remove switches/computers without having to power down the switches
• Two level password security - only authorized users view and control the computers - up to four Users plus an Administrator with separate profi les for each
• Two level logout - Manual and Timed
• PS/2 keyboard and mouse emulation - computers boot even when the console focus is elsewhere
• Superior video quality - supports resolutions of up to 1600 x 1200 @ 60Hz
• Multi-language keyboard support: American/UK English; Traditional Chinese; Japanese; French; German; Korean
• Rack Mountable in 19" System Rack (1U)
QUICK SPECIFICATIONS
• Product Type: KVM Switch
• Computer
Connections: Direct 8, Max. 256 (via Daisy Chain)Port Selection
• Port Selection: OSD (On Screen Display); Hotkeys Pushbuttons
• KVM Ports: 8 x RJ-45 Female
• Daisy Chain: In 1 x DB-25 Female (Black)
, Out 1 x DB-25 Male (Black)
• F/W Upgrade: 1 x RJ-11 Female (Black)
• Power: 1 x 3-prong AC socket
• Port: On Line 8 (Green),
Selected 8 (Orange)
• Power: 1 (Blue)
• Station ID: 1 x 2 Digit 7-segment (Orange)
• Emulation: Keyboard / Mouse PS/2; USB
• Scan Interval: 1255 sec.
• Video: 1600 x 1200 @ 60 Hz (40 m);,
1280 x 1024 @ 75 Hz (50 m)
• I/P Rating: 100240V AC; 50/60 Hz; 1A
• Power Consumption: 120V/5.8W; 230V/6W
WHAT'S INCLUDED
• KH1508 KVM Switch
• User Instructions
Do you have a question about this product? Please call 1800 90 90 99.
KH1508A-AX-U
New
10000 Items
Specific References
- MPN
- KH1508A-AX-U
The KH1508 KVM Switch is a control unit that allows access to multiple computers from a single KVM console. The KH1508 features RJ-45 connectors and Cat 5 cable to link to the computers.
