The Aten KH1532A-AX-U KVM switch is a control unit that allows IT administrators to access and control multiple computers from a single PS/2 or USB KVM console (keyboard, monitor, and mouse). . Operators can take control of up to 32 (KH1532A) computers. By daisy-chaining up to 31 additional switches, as many as 1024 computers can be controlled from a central KVM console. These switches have been designed with unique and powerful features that enable administrators to manage their entire server room and data center devices easily and conveniently. ID, port name, OS, keyboard language, and more. This feature allows administrators to relocate servers to different ports without having to reconfigure the adapters. Other advantages found with these switches include Full HD video quality and the ability to extend the distance to the servers to up to 50 m* at a resolution of 1280 x 1024. A KH1532A installation provides one of the best and most economical solutions ATEN has to offer the SMB market. There is no better way to save a data center time, space, and money than with a KH1532A KVM switch.

Brand New - A brand-new, unused, unopened, undamaged item in its original packaging.

This item comes with a 24-month manufacturer's warranty.

• One KVM console controls up to 32 directly connected computers
By daisy-chaining up to 31 additional KH1532A switches, as many as 1024 computers can be controlled from the original KVM console
• Superior Video Quality- Supports video resolutions up to 1920 x 1200 @60Hz for up to 30 meters*, 1600 x 1200 @60Hz for up to 40 meters, and 1280 x 1024 @75Hz for up to 50 meters
• Three port selection methods: Manual (via front panel pushbuttons), Hotkey, and multi-language OSD (On Screen Display)

• Product Type: Rackmount KVM
• Computer Connections:
- Direct 32
- Maximum 1024 (via Daisy-chain)
• Port Selection: OSD, Hotkey, Pushbutton
• Console Ports:
- 2 x USB Type A Female
- 1 x 6-pin Mini-DIN Female (Purple)
- 1 x 6-pin Mini-DIN Female (Green)
- 1 x HDB-15 Female (Blue)
• KVM Ports: 32 x RJ-45 Female
• Daisy Chain Ports:
- 1 x DB-25 Female (Black)
- 1 x DB-25 Male (Black)
• Firmware Upgrade: 1 x RJ-11 Female
• Power: 1 x IEC 60320/C14
• Power Consumption: DC5V:5.37W:40BTU
• Operating Temperature: 0 - 40°C
• Storage Temperature: -20 - 60°C
• Humidity: 2.81 kg ( 6.19 lb )
• Housing: Metal
• Weight: 0.88 kg ( 1.94 lb )
• Dimensions (L x W x H): 43.72 x 16.37 x 4.40 cm (17.21 x 6.44 x 1.73 in.)

• 1x KH1532A Cat 5 High-Density KVM Switch
• 1x Firmware Upgrade Cable
• 1x Power Cord
• 1x Rack Mount Kit
• 1x Foot Pad Set (4 pcs.)
• 1x User Instructions

Do you have a question about this product? Please call 1800 90 90 99.
